10.12 Input/Output Board Connections - 2
The diagram below illustrates the connections between the I/O board and the CDU
cup sensor, dispense head opto sensor, turret position switch and dispense head home
switch.
80
Technical Manual
WASTE
PROBE
DISPENSE HEAD
OPTO SENSOR
FLOW
METER
CDU CUP
SENSOR
INPUT/OUTPUT BOARD
BLUE/GREEN
YELLOW/GREY
