Pos Item Name
1 B03 Limit switch, door open soiled side
2 B17 Limit switch, door closed soiled side
3 V11 Valve, waste water to T1
4 V13 Valve, waste water to T2
5 Tank 1
6 Tank 2
7 E03 Machine light 1
8 S52 Crush protection door, soiled side
9 B03 Pressure differential sensor
10 V01 Valve, cold water
11 V02 Valve, hot water
12 V03 Valve, high quality water
13 M07 Drying blower
14 M15.2 Motor 2, nozzle turn
15 V19.2 Cylinder 1, cart connection
16 M12 Door motor soiled side
17 S54 Force protection, door clean side
18 V31.2 Cylinder 2, locked door clean side
19 S05.2 Limit switch, door clean side locked 2
20 S06.2 Limit switch, door clean side unlocked 2
21 V31.1 Cylinder 1, locked door clean side
22 S05.1 Limit switch, door clean side locked 1
23 S06.1 Limit switch, door clean side unlocked 1
24 V14 Valve, waste water from tank 2
25 S106 Safety line
26 V30 Cylinder, threshold clean side
27 S12 Limit switch, door clean side bridge out
28 A112 Operating panel OP10
29 S104, S105 Machine stop, door clean side auto
30 V05 Valve, heating dryer
31 KL01 Cabinet, softstart
32 AS1 Cabinet control system
33 T00 Transformer
34 Q00 Main switch
35 B04 Temperature sensor
