Getinge 9125 - Page 36

Plotgraph (2.1.2)
When PLOT GRAPH is selected, the screen (1.2) becomes the process screen, while you go up one level
in the menu tree and end up in the process screen.
49,1 C
WASH1 TEMP SP
P1 HC SHORT 00:12:24
01 STANDBY 00:02:22
A34 I/O FAULT
00:03:00
WASH1 TIME
128,1 C
DRYER TEMP
SET UP
SELECT
CYCLE
PARA-
METERS
DISCHARGE PRESS
WASH1 TEMP SP
BAR
C
000714
1
32
8
7
9
10
6
5
4
11
12
1. WASH1 TEMP SP.
2. WASH1 TIME
3. DRYER TEMP
4. PARAMETERS
5. SELECT CYCLE
6. SETUP
7. A34 I/O FAULT
8. GRAPH
9. WASH1 TEMP SP
10. DISCHARGE PRESS
11. STANDBY
12. HC SHORT
