GW Instek PSW Series User Manual

PSW Series User Manual
128
3. Press the Output key. The current
can now be controlled with the
External resistance.
Output
Note
Ensure the resistor(s) and cables used exceed the
isolation voltage of the power supply. For example:
insulation tubes with a withstand voltage higher
than the power supply can be used.
When choosing an external resistor ensure the
resistor can withstand a high degree of heat.
Note
CV and CC Slew Rate Priority are disabled for V-I
mode (F-03) when using external resistance
control. See the normal function settings on page
102.
External Control of Output
Background
The output can be turned on or off externally
using a switch. The analog control connector
can be set to turn the output on from a high or
low signal. The voltage across pins 2 and 24 are
internally pulled to +5V ±5% @ 500uA with
10kΩ pull-up resistor. A short (closed switch)
produces a low signal.
When set to High = On, the output is turned on
when the pins 2-24 are open.
When Low = On, the output is turned on when
pins 2-24 are shorted.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
