GW Instek PSW Series User Manual

PSW Series User Manual
46
Output Terminals PSW-250/800
Background
The high voltage models (PSW 250 and PSW
800 models) use a 9 pin socket for the output
voltage and sense connections. The
corresponding plugs (GW part number 39BT-
50900401 //DECA SwitchLab MC420-38109Z)
should be used to connect the terminals to the
appropriate cable.
Before connecting the output terminals to the
load, first consider whether voltage sense will
be used, the gauge of the cable wiring and the
withstand voltage of the cables and load.
WARNING
Dangerous voltages. Ensure that the power to the
instrument is disabled before handling the power
supply output terminals. Failing to do so may lead
to electric shock.
Please note the wire gauge used and the capacity
of the plug/socket. It may be necessary to wire the
load to a number of terminals to offset the
capacity over a number of terminals.
Output Connector
Overview
When using the output connector make sure
the wires that are used follow the following
guidelines:
Wire gauge:
AWG 26 to AWG 16
Strip length
6.5mm // 0.26 in.
Current rating
10A
Insulation resistance
AC 2000V min
Insulation withstand
voltage
>2000MΩ DC500V
Operation
Temperature
-40ºC to +105ºC

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
