Parallel / Series Operation
This section describes the basic operations required to operate the
power supply in series or parallel. Operating the PSW series in
parallel increases the total power output of the power supply units.
When used in series, the total output voltage of the power supplies
can be increased.
The number of the power supplies that can be connected in series
or parallel depends on the model and the mode:
 Series Mode: 2 units maximum; 30V, 80V and 160V models only.
Parallel Mode: 3 units maximum
CAUTION
250V and 800V models do not support series
operation!
To use the power supplies in series or parallel, units must be used
in a Master-Slave configuration. In the master-slave configuration a
“master” power supply controls any other connected “slave”
power supplies.
 Master-Slave Parallel overview → from page 73
 Parallel connection → from page 76
 Parallel operation → from page 79
 Master-Slave Series overview → page 81
 Series connection → page 83
 Series operation → from page 85
Before operating the power supply, please see the Getting Started
chapter, page 9.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
