GW Instek PSW Series User Manual

OPERATION
95
Note
Error messages: If you try to remove a test script
from an empty memory location “Err 003” will be
displayed on the display.
Checking the Available Memory
Overview
The T-05 function displays the amount of
internal memory that is left on the unit to load
test scripts. The displayed units are in kilobytes
(1024 bytes).
Steps
Select T-05 (Test Memory). The
available memory in kilobytes is
displayed.
Page 89
T-05 range
1~1848 KB

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
