GW Instek PSW Series User Manual

OPERATION
93
Note
*Setting F-92 to 0 or 1 will disable loading a test
script at startup. 0 will turn the output off at
startup. 1 will turn the output on at startup. See
the power on configuration settings for details,
page 110.
Note
When a script starts to run, there is no way to abort
the script. Pressing the Output key has no effect. If
you wish to stop a test early, turn the power off.
Export Test Script to USB
Overview
The Export Test function saves a test file to the
root directory of a USB flash drive.
 Files will be saved as tXXX.tst where XXX is
the memory number 001~010 from which
the test script was exported from.
 Files of the same name on the USB flash
drive will be written over.
Steps
1. Insert a USB flash drive into the
front panel USB-A slot.
2. Turn on the power. MS (Mass Storage) will be
displayed on the screen after a few seconds if
the USB drive is recognized.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
