GW Instek PSW Series User Manual

PSW Series User Manual
94
Note
If the USB drive is not recognized, check to see
that the function settings for F-20 = 1 (page 106). If
not, reinsert the USB flash drive.
3. Configure T-03 (Test Export) to
0~10 (save memory slot)
Page 89
T-03 range
1~10
4. The script will now be copied to the USB flash
drive.
Note
Error messages: If you try to export a test script
from an empty memory location “Err 003” will be
displayed on the display.
Remove Test Script
Overview
The Remove Test function will delete a test
script from the internal memory.
Steps
1. Select T-04 (Test Remove) and
choose which test script to remove
from the internal memory.
Page 89
T-04 range
1~10
2. The test script will be removed from the
internal memory.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
