GW Instek PSW Series User Manual

OPERATION
91
Note
If the USB drive is not recognized, check to see
that the function settings for F-20 = 1 (page 106). If
not, reinsert the USB flash drive.
3. Configure T-02 (Test Load) to 1~10
(save memory slot)
Page 89
T-02 range
1~10 (t001 ~t010)
4. The script will now be available in the memory
slot the script was saved to.
Note
Error messages: If you load a file that is not
present on the USB drive “Err 002” will be
displayed on the display.
Run Test Script (Manual)
Overview
A test script can be run from one of ten memory
slots.
Steps
1. Before a test script can be run, it
must first be loaded into one of the
10 memory save slots.
Page 90
2. Configure T-01 (Run Test) to 1~10
(save memory slot#)
Page 89
T-01 range
1~10
3. The test script will automatically start to run.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
