PSW Specifications
The specifications apply when the PSW is powered on for at least
30 minutes.
PSW 360W
PSW 30-36, PSW 80-13.5, PSW 160-7.2, PSW 250-4.5,
800-1.44
Model
Unit
PSW
30-36
PSW
80-13.5
PSW
160-7.2
PSW
250-4.5
PSW
800-1.44
Rated Output Voltage
V
30
80
160
250
800
Rated Output Current
A
36
13.5
7.2
4.5
1.44
Rated Output Power
W
360
360
360
360
360
Power Ratio
--
3
3
3.2
3.125
3.2
Constant Voltage Mode
Line Regulation (*1)
mV
18
43
83
128
403
Load Regulation (*2)
mV
20
45
85
130
405
Ripple and Noise (*3)
p-p (*4)
mV
60
60
60
80
150
r.m.s (*5)
mV
7
7
12
15
30
Temperature coefficient
ppm
/ºC
100ppm/°C of rated output voltage, after a
30 minute warm-up.
Remote sense compensation
voltage (single wire)
V
0.6
0.6
0.6
1
1
Rise Time (*6)
Rated Load
ms
50
50
100
100
150
No Load
ms
50
50
100
100
150
Fall Time (*7)
Rated Load
ms
50
50
100
150
300
No Load
ms
500
500
1000
1200
2000
Transient response time (*8)
ms
1
1
2
2
2
Constant Current Mode
Line regulation (*1)
mA
41
18.5
12.2
9.5
6.44
Load regulation (*9)
mA
41
18.5
12.2
9.5
6.44

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
