GW Instek PSW Series User Manual

APPENDIX
163
Ripple and noise
r.m.s (*5)
mA
72
27
15
10
5
Temperature coefficient
ppm
/ºC
200ppm/°C of rated output current, after a
30 minute warm-up.
Protection Function
Over voltage protection
(OVP)
Setting range
V
3-33
8-88
16-176
20-275
20-880
Setting accuracy
± (2% of rated output voltage)
Over current protection
(OCP)
Setting range
A
3.6-
39.6
1.35-
14.85
0.72-
7.92
0.45-
4.95
0.144-
1.584
Setting accuracy
± (2% of rated output current)
Over temperature protection
(OTP)
Operation
Turn the output off.
Low AC input protection
(AC-FAIL)
Operation
Turn the output off.
Power limit (POWER LIMIT)
Operation
Over power limit.
Value (fixed)
Approx. 105% of rated output power
Analog Programming and Monitoring
External voltage control
output voltage
Accuracy and linearity: ±0.5% of rated
output voltage.
External voltage control
output current
Accuracy and linearity: ±1% of rated output
current.
External resistor control
output voltage
Accuracy and linearity: ±1.5% of rated
output voltage.
External resistor control
output current
Accuracy and linearity: ±1.5% of rated
output current.
Output voltage monitor
Accuracy
%
±1
±1
±1
±2
±2
Output current monitor
Accuracy
%
±1
±1
±1
±2
±2
Shutdown control
Turns the output off with a LOW (0V to
0.5V) or short-circuit.
Output on/off control
Possible logic selections:
Turn the output on using a LOW (0V to
0.5V) or short-circuit, turn the output off
using a HIGH (4.5V to 5V) or open-circuit.
Turn the output on using a HIGH (4.5V to
5V) or open-circuit, turn the output off
using a LOW (0V to 0.5V) or short-circuit.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
