GW Instek PSW Series User Manual

PSW Series User Manual
90
Exit
Press the Test key again to exit the
Test settings. The Test key light
will turn off.
Test
Load Test Script from USB
Overview
Before a test script can be run, it must first be
loaded into a one of the 10 memory save slots.
Before loading a test script into memory:
 Ensure the script file is placed in the root
directory.
 Ensure the file name number corresponds to
the memory number that you wish to save
to.
For example: A test file named t001.tst can
only be saved to memory number 01, t002.tst
can only be saved to memory number 02,
and so on.
Steps
1. Insert a USB flash drive into the
front panel USB-A slot. Ensure the
flash drive contains a test script in
the root directory.
2. Turn on the power. MS (Mass Storage) will be
displayed on the screen after a few seconds if
the USB drive is recognized.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
