GW Instek PSW Series User Manual

OPERATION
89
Setting the Test Script Settings
Steps
The test script settings (T-01~T-04) are set with
the Test key.
1. Press the Test key. The Test key
will light up.
Test
2. The display will show T-01 on the top and the
memory no. for T-01 on the bottom.
Test Setting
Memory
number
3. Rotate the Voltage knob to change
the T setting (Test setting).
Voltage
Test Run
Test Load
Test Export
Test Remove
Test Memory
T-01
T-02
T-03
T-04
T-05
4. Rotate the Current knob to choose
a memory number.
Current
Range
1~10
5. Press the Voltage knob to complete
the setting.
Voltage

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
