GW Instek PSW Series User Manual

PSW Series User Manual
92
Note
Error messages: If you try to run a test script from
an empty memory location “Err 003” will be
displayed on the display.
Note
When a script starts to run, there is no way to abort
the script. Pressing the Output key has no effect. If
you wish to stop a test early, turn the power off.
Run Test Script (Automatically at Startup)
Overview
The power supply can be configured to
automatically run a test script at startup.
Steps
1. Before a test script can be run, it
must first be loaded into one of the
10 memory save slots.
Page 90
2. Turn the unit off.
3. Enter the power-on configuration
settings and set F-92 (Power-ON
Output) to run the desired test
script.
Page 114
Range
T001~T010*
4. The selected test script will automatically start
to run the next time the unit is powered on.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
