GW Instek PSW Series User Manual

PSW Series User Manual
50
Using the Output Terminal Cover PSW-250/800
Steps
1. Screw the bottom
cover onto the rear
panel using the two
M4 screws.
1
2. Slide the top cover
over the bottom
cover.
2
3. Finally, secure the
top cover with the
screw in the center of
the top cover.
3
Removal
Reverse the procedure to remove the terminal
covers.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
