GW Instek PSW Series User Manual

PSW Series User Manual
126
4. Press the Output key. The voltage
can now be controlled with the
External resistance.
Output
Note
Ensure the resistor(s) and cables used exceed the
isolation voltage of the power supply. For example:
insulation tubes with a withstand voltage higher
than the power supply can be used.
When choosing an external resistor ensure the
resistor can withstand a high degree of heat.
Note
CV and CC Slew Rate Priority are disabled for V-I
mode (F-03) when using external resistance
control. See the normal function settings on page
102.
External Resistance Control of Current Output
Background
External resistance control of the current output is
accomplished using the MIL-26 connector on the
rear panel. A resistance of 0kΩ~10kΩ is used to
control the full scale current of the instrument.
The output current (0 to full scale) can be
controlled with the external resistance going up
(Ext-R ) 0kΩ~10kΩ(10kΩ = Vo,max) or down
(Ext-R ) 10kΩ~0kΩ(10kΩ = 0).
For 0kΩ~10kΩ: Output current = full scale current
× (external resistance/10)
For 10kΩ~0kΩ: Output current = full scale current
× ([10-external resistance]/10)

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
