GW Instek PSW Series User Manual

PSW Series User Manual
106
Bleeder Control
Bleeder control turns ON/OFF the bleeder
resistor. Bleeder resistors discharge the filter
capacitors after power is turned off as a safety
measure.
F-09
0 = OFF, 1 = ON
Buzzer ON/OFF
Turns the buzzer sound on or off. The buzzer is
associated with alarm sounds and keypad entry
sounds.
F-10
0 = OFF, 1 = ON
Measurement
Average Setting
Determines the level of smoothing for the
average setting.
Only available for firmware version 1.5 or
above.
F-17
0 = Low, 1 = Middle, 2 = High
Lock Mode
Determines the behavior of the Output key
when the panel lock is on.
Only available for firmware version 1.54 or
above.
F-19
0 = Panel lock: allow output off,
1 = Panel lock: allow output
on/off
USB/GPIB Settings
Front Panel USB
State
Displays the front panel USB-A port state. This
setting is not configurable.
F-20
0 = Absent, 1 = Mass Storage

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
