MIDI TEMPLATES
CHANNELS AND MIDI MESSAGES
Template Seq. Local Seq. No Local Use Ex Zone
Messages Local Control
On Off On
NRPN
On On On
Leslie Control Code
Organ Organ Organ
Transmit Channel Swell Keyboard
11Off
Great Keyboard
22Off
Pedal Keyboard
33Off
External Zone
Off Off On
Control
16 16 Off
Leslie
Off Off Off
Comments
Use this template for connect-
ing the organ to an external
MIDI sequencer without the
“Echo Back” (or MIDI thru)
function, and recording songs.
Use this template for connect-
ing the organ to an external
MIDI sequencer with the
“Echo Back” (or MIDI thru)
function, and recording songs.
Use this template for connect-
ing the organ to an external
MIDI sound generator, such as
a synthesizer or a sound mod-
ule, to play it from the organ.
External Zone
(Tx. only)
Swell
Keyboard
Great
Keyboard
Pedal
Keyboard
Control
Note
OOOOX
Pitch Bend
O X X X O *1
Modulation (1)
O X X X O *1
Volume, Pan (7, 10)
OXXXX
Expression (11)
O X X X O *2
Hold 1 (64)
OOOOX
Drawbar Reg. Swell: 12 - 20
Great: 21 - 29
Pedal: 33,35
XXXXO
Spring Shock (48)
XXXXO
Extra Voice Volume (83)
XXXXO
RPN (100, 101)
XXXXX
NRPN (98, 99)
XXXXO
All Notes O (123)
OOOOX
All Sounds O (120)
X O *3 O *3 O *3 X
Reset All Ctrl. (121)
OOOOO
After Touch
XXXXX
Bank Select (0, 32)
Change the voice for
each zone.
X X X Combination Presets
Program Change
XXX
*1: It works for both Swell, Great and Pedal.
*2: It works for all parts (audio controlled)
*3: For Rx. only.
