5
1
/3'
16' 8' 4'
2
2
/3'
2'
1
3
/5'1
1
/3'
1'
5
1
/3'
16' 8' 4'
2
2
/3'
2'
1
3
/5'1
1
/3'
1'
5
1
/3'
16' 8' 4'
2
2
/3'
2'
1
3
/5'1
1
/3'
1'
8'
16'
35
Setting Up
Manual Drawbars
White Drawbars
In each Drawbar set, the white Drawbar (8´) plays in the basic
octave of the organ. e other drawbar pitches are fi gured in
reference to this pitch, up or done. e other white Drawbars
get higher by the octave to the right.
Black Drawbars
Brown Drawbars
Pedal Drawbars
e sounds of the black Drawbars, play important roles in
building rich tones. eir pitches are octave-fi fth and octave-
third to the fundamental. ey contain the elements of all dif-
ferent harmonics such as those in the sounds of sweet and soft
horn, mellow strings among others.
e two brown Drawbars on the far left give depth and richness
to the sound. e left 16´ is one octave lower than the 8, and
5⅓ ´ is the third harmonic of the 16´ fundamental.
e Pedal Part which plays the bass line uses the two Drawbars
- 16´ and 8´.
e fi rst Pedal Drawbar produces a tone at 16´ pitch for a deep
foundation bass, while the second Pedal Drawbar produces a
tone at 8´ pitch, or one octave higher.
e registration of the Pedal Part is displayed on the center of
the display, the left one is 16´, and the right is 8´.
