Owner’s Manual
134
SPECIFICATIONS
Sound Generator
Drawbars
2 - VASE III as Digital Tone-wheels, 61 polyphony
Extra Voice
80 polyphony
Keyboards
Swell: C1 to C6 61-key
Great: C1 to C6 61-key
Pedal: 13-note attached
Harmonic Drawbars
Drawbars
Swell: 9 Pitches
Great: 9 Pitches
Pedal: 2 Pitches
Voicing
Manuals: 5 choices (B-Type1, B-Type2, Mellow, Brite, Sawtooth), valiable
key-click
Pedal: 4 choices (Normal, Muted, Synth1, Synth2), 5 choices key-click
Touch Response Percussion
Buttons
Second Harmonic, ird Harmonic, Fast Decay, Volume Soft
Adjustable
Touch, Velocit, Decay (Fast, Slow), Level (Normal, Soft)
Extra Voice
Instruments
880 Instruments, 56 Drum Kits
General MIDI Level 1 upper compatible
Parts
1 Part per keyboard
E ects
Internal Leslie
Advanced Digital, 2 Rotors
Buttons: On, Fast
Vibrato and Chorus
Digital Scanner
Rotary Mode Knob: V1, V2, V3, C1, C2, C3
Buttons: Swell On, Great On
Overdrive
Digital
Equalizer
Drawbars: Bass, Mid (sweep), Treble, Tone
Extra Voice: Bass, Mid (sweep), Treble
Reverb
Digital, 11 programs (Drawbars), 6 programs (Extra Voice)
Knob: Reverb Depth
Chorus
6 programs (Extra Voice)
Sustain
Pedal Drawbars, Pedal Extra Voice
Tuning
Master
430 - 450 1Hz Steps
Transpose
-6 to +6 semitones
Coupler
Buttons
Pedal to Great, Great to Pedal
Adjustable
Highest note
Combination Presets
Capacity
9 Banks, 9 Presets
Preset Load Option
Drawbar Registration, Drawbar Parameters, Percussion, Extra Voice, In-
ternal Zone, External Zone, EQ/Reverb, Animation/OD
Controllers
Volumes
Master Volume, External Leslie Volume, Extra Voice Volume
Wheels
Pitch Bend, Modulation
Pedal
Expression Pedal w/1 - Foot Switch
Sequencer
SMF compatible Sequence Recorder w/ Simple Rhythm Player
3 Control Buttons
Storage
Compactfl ash Card Slot
Display
20 - Characters, 2 - Lines
9 Control Buttons
MIDI
Templates
3 Templates
External Zones
1 Zone per keyboard
Connections
MIDI
In (Keyboard), In (Multi), Out
Audio
Line In L, R, Microphone In w/Volume control,
Line Out L, R, Headphones
Leslie
11 - pin, 1 to 3 channels available
Other
Foot Switch
Sound System
Ampli cation
2 - 50 watt RMS amplifi er
Speakers
2 - 10cm Tweeter, 2 - 30cm Woofer
Dimensions
without music rack: 920(H), 1145(W), 650(D) mm
with music rack: 1120(H), 1145(W), 650(D)mm
Bench: 650(W), 595(H), 265(D)mm
Weight
Organ: 95kg, Bench: 9kg
