15
Introduction
Rear Panel
Manual Bottom
43. FOOT SWITCH Jack
is jack is for Foot Switch (= FS-9H - optional) and the Leslie
Switch (= CU-1 - optional).
You can switch the speed of the Leslie eff ect and the Combina-
tion Preset, etc. while playing. (P. 20)
44. HEADPHONES Jack
is is for connecting the stereo headphones. e speakers are
turned off , when a plug is inserted to this jack. (P. 19)
45. MICROPHONE VOLUME Knob
is adjusts the volume of the microphone (#46).
NOTE: The microphone volume can be adjusted with the MASTER
VOLUME (#2) and EXT. LESLIE VOLUME (#3) knob.
46. MICROPHONE Jack
If you plug a microphone into the this jack, you can use the this
organ as a public-address system.
NOTE: Feedback could be produced depending on the location of
microphone relative to speakers. This can be prevented by:
- Changing the position of the microphone.
- Relocating microphone at a greater distance from speakers.
- Lowering volume levels.
47. LINE IN L, R Jack
is is the input for an external sound module or a CD player.
e signals input to this jack are routed to the built-in speak-
ers, LINE OUT jack, HEADPHONE jack, and the stationary
channel of Leslie Speaker.
NOTE: The line in volume can be adjusted with the MASTER VOLUME
(#2) and EXT. LESLIE VOLUME (#3) knob.
48. LINE OUT L Jack
is is the Left channel output of this organ.
49. LINE OUT R Jack
is is the Right channel output of this organ.
Use the Left and Right output jacks if your mixer or amplifi er
has a stereo input.
50. MIDI OUT Jack
Sends out the performance information of this organ. (P. 84)
51. MIDI IN1 (KEYBOARD) Jack
is jack is for playing the keyboard channels (SWELL,
GREAT, PEDAL) from external MIDI equipment. (P. 84)
52. MIDI IN 2 (MULTI) Jack
is jack is for playing the built-in 16 part multi-timbral sound
engine from external MIDI equipment. (P. 84)
53. LESLIE 11 PIN Socket
Connect the Leslie speaker here. (P. 18)
HEAD
PHONE
FOOT
SWITCH 2
SEQUENCER
MIN. MAX.
VOLUME IN L R L R
(KEYBOARD) (MULTI)
OUT
MICROPHONE LINE IN LINE OUT
LESLIE 11PIN
MIDI
IN 1 IN 2
43
44
45 46 47 48 49
50 51 52
53
