Global Parameters
Category Parameter NRPN SysEx Address SysEx
Length
Data Default Description
LSB
(62)
MSB
(63)
MSB to LSB
Tune
Transpose
01 00 00 01 00 01
3A - 40 - 46
(-6 - 0 - 6)
40 0
Master Tune
01 02 00 01 02 02
032E - 0338 - 0342
(430 - 440 - 450)
0338 440
Expression
Source
02 00 00 02 00 01
00 - 02
00: Auto
01: Internal
02: MIDI
01 Auto
Min. Level
02 08 00 02 08 01
00 - 09
(Off , -40dB - 0dB)
06 -35dB
Min. Limit LF
02 09 00 02 09 01
00 - 08
(Off , -40dB - -5dB)
05 -20dB
Min. Limit HF
02 0A 00 02 0A 01
03 -30dB
Foot Switch
FS1 Mode
02 01 00 02 01 01
00 - 0B
00: Off
01: Leslie Fast (alternate)
02: Leslie Fast (momentarily)
03: Dampler Swell
04: Damper Great
05: Damper Pedal
06: Preset Fwd.
07: Preset Rev.
08: Spring Shock
09: Delay Time
0A: Rhythm Start/Stop
0B: Rhythm Fill In
01 Leslie Fast (alternate)
FS2 Device
02 02 00 02 02 01
00 - 01
(Foot Sw., Leslie Sw.)
00 Foot Sw.
FS2 Tip Mode
02 03 00 02 03 01
same as FS1 mode 01 Leslie Fast (alternate)
FS2 Ring Mode
02 04 00 02 04 01
same as FS1 mode 01 Leslie Fast (alternate)
Damper Drawbars
02 05 00 02 05 01
00, 01 (Off /On) 01 On
Damper Extra Voice
02 06 00 02 06 01
00, 01 (Off /On) 01 On
Damper External Zone
02 07 00 02 07 01
00, 01 (Off /On) 01 On
Example Set Transpose 0 via NRPN ....................................Bx 62 01 63 00 06 40 (x = Control channel)
Set Transpose 0 via System Exclusive .....................F0 55 dd 10 1D 13 00 01 00 40 F7 (dd = Device ID)
Bank Parameters
Category Parameter NRPN SysEx Address SysEx
Length
Data Default Description
LSB
(62)
MSB
(63)
MSB to LSB
Preset Load
Drawbar Regist. Swell
6b 00 00 6b 00 01
00, 01 (Off /On) 01 On
Drawbar Regest. Great
6b 01 00 6b 01 01
00, 01 (Off /On) 01 On
Drawbar Regist. Pedal
6b 02 00 6b 02 01
00, 01 (Off /On) 01 On
Internal Zone (INT)
6b 03 00 6b 03 01
00, 01 (Off /On) 01 On
External Zone (EXT)
6b 04 00 6b 04 01
00, 01 (Off /On) 01 On
Extra Voice (EXV)
6b 05 00 6b 05 01
00, 01 (Off /On) 01 On
Equalizer / Reverb (EQ/REV)
6b 06 00 6b 06 01
00, 01 (Off /On) 01 On
Animation / Overdrive
(ANI/OD)
6b 07 00 6b 07 01
00, 01 (Off /On) 01 On
Drawbar (DRAWB)
6b 08 00 6b 08 01
00, 01 (Off /On) 01 On
Percussion (PERCUS)
6b 09 00 6b 09 01
00, 01 (Off /On) 01 On
Example “b” means Bank number.
Set Bank 2 Animation On via NRPN ...................Bx 62 61 63 07 06 01 (x = Control channel)
Set Bank 2 Animation On via System Exclusive ....F0 55 dd 10 1D 13 00 61 07 01 F7 (dd = Device ID)
