Owner’s Manual
88
USING A MIDI COMPATIBLE LESLIE SPEAKER
If you connect this organ and the Leslie speaker through MIDI, you can send the
Leslie parameters such as the rotor speed and the rise time to the Leslie speaker and
can make fi ner adjustment than connecting them only with the Leslie cable.
1. Hook up as illustrated.
2. Recall the “Seq. Local” by the MIDI template.
3. Set MIDI MAST - LES (P. 92 #4) at “21”.
4. Set the Leslie MIDI Channel (P. 93 #14).
Set the Leslie MIDI channel of the organ at the same value as the Leslie speaker MIDI
channel.
5. If you operate the Leslie parameters on this organ or call out the Combination Presets,
these Leslie parameters are sent to the Leslie speaker.
MIN. MAX.
VOLUME IN L R L / MONO R
(KEYBOARD) (MULTI)
OUT
MICROPHONE LINE IN LINE OUT
LESLIE 11PIN
MIDI
IN 1 IN 2
MIDI compatible
Leslie Speaker
MIDI cable
Leslie cable
To Next Page
