Owner’s Manual
122
MIDI Implementation
Channel Voice Message
Note Off
Status 2nd Byte 3rd Byte
8nH kkH vvH, or
9nH kkH 00H
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity(disregard): 00H - 7FH (0 - 127)
Note On
Status 2nd Byte 3rd Byte
9nH kkH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
kk=Note Number: 00H - 7FH (0 - 127)
vv=Velocity: 00H - 7FH (0 - 127)
Control Change
The value set by the Control Change is not reset even when Program Change
messages etc. are received.
Bank Select (CC#0, 20)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
mm,ll=Bank Number: 00 00H - 7F 7FH
Until you send the Program Change, the Bank Select process is reserved.
Modulation 1 (CC#1)
Status 2nd Byte 3rd Byte
BnH 01H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Modulation depth: 00H - 7FH (0 - 127)
Modulation 2 (CC#2)
Status 2nd Byte 3rd Byte
BnH 01H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Modulation depth: 00H - 7FH (0 - 127)
Portamento Time (CC#5)
Status 2nd Byte 3rd Byte
BnH 05H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Portamento Time: 00H - 7FH (0 - 127)
This adjusts the rate of pitch change when Portamento is on. A value of 0 re-
sults in the fastest change.
Volume (CC#7)
Status 2nd Byte 3rd Byte
Bn 07 vv
n=MIDI Channel Number: 0 - F (Ch. 1 - 16)
vv=volume: 00 - 7F (0 - 127)
The volume message is used to set the volume balance of each External Zone
and Extra Voice.
Pan (CC#10)
Status 2nd Byte 3rd Byte
BnH 0AH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Pan: 00H(Left) - 40H(Center) - 7FH(Right)
Expression (CC#11)
Status 2nd Byte 3rd Byte
BnH 0BH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Expression: 00H - 7FH (0 - 127)
Damper (CC#64)
Status 2nd Byte 3rd Byte
BnH 40H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
Portamento (CC#65)
Status 2nd Byte 3rd Byte
BnH 41H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0=Off, 1 - 127=On
Sostenuto (CC#66)
Status 2nd Byte 3rd Byte
BnH 42H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
Soft (CC#67)
Status 2nd Byte 3rd Byte
BnH 43H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H - 7FH (0 - 127)
0 - 63=Off, 64 - 127=On
Filter Resonance (CC#71)
Status 2nd Byte 3rd Byte
BnH 47H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
Release Time (CC#72)
Status 2nd Byte 3rd Byte
BnH 48H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
Attack Time (CC#73)
Status 2nd Byte 3rd Byte
BnH 49H vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
Filter Cut Off (CC#74)
Status 2nd Byte 3rd Byte
BnH 4AH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
Decay Time (CC#75)
Status 2nd Byte 3rd Byte
BnH 4BH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
Vibrato Rate (CC#76)
Status 2nd Byte 3rd Byte
BnH 4CH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
Vibrato Depth (CC#77)
Status 2nd Byte 3rd Byte
BnH 4DH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
Vibrato Delay (CC#78)
Status 2nd Byte 3rd Byte
BnH 4EH vvH
n=MIDI Channel Number: 0H - FH (Ch. 1 - 16)
vv=Control Value: 00H(-64) - 40H(0) - 7FH(+63)
MIDI INFORMATION FOR MULTI 16 DIV.
