Drawbar Data List
Control Number
Part 16´ 5 ⁄´ 8´ 4´ 2 ⁄´ 2´ 1 ⁄´ 1 ⁄´ 1´
Swell
0CH(12) 0DH(13) 0EH(14) 0FH(15) 10H(16) 11H(17) 12H(18) 13H(19) 14H(20)
Great
15H(21) 16H(22) 17H(23) 18H(24) 19H(25) 1AH(26) 1BH(27) 1CH(28) 1DH(29)
Pedal
21H(33) - 23H(35) - - - - - -
Level
012345678
Value
00 - 0FH
(0 - 15)
10 - 1FH
(16 - 31)
20 - 2FH
(32 - 47)
30 - 3FH
(48 - 63)
40 - 4FH
(64 - 79)
50 - 5FH
(80 - 95)
60 - 6FH
(96 - 111)
70 - 7EH
(112-126)
7FH
(127)
ex: Set Great 8´ to level 7 via MIDI... Bx 17 70 (x=Control Channel)
