Owner’s Manual
78
EQUALIZ (EQUALIZer)
In this mode, you can adjust the settings for the Equalizer.
An Equalizer is used to adjust the tonal quality. e built-in Equalizer consists of 3
bands and Tone Control. With the 3 bands ranging bass to treble, you can boost or
cut any of them.
To locate this mode:
Touch the [MENU] button for the MENU, select page C by the [PAGE] button, and
then touch the [2] EQUALIZ button.
DRAWBARS
1. TONE CONTROL
is models the “screw-set” tone control that was present on the preamp inside of
the vintage Hammond B-3. It gently cuts the treble.
e setting range is -9 to +9, and it becomes neutral when set at “0”.
“-1” corresponds to the maximum of the B-3/C-3 tone control, “-5”, the middle,
“-9” the minimum. e tone control found on the B-3/C-3, it’s value can not be set
at “+”, but on this model it’s possible to boost treble to some extent.
2. GAIN - BASS
3. GAIN - MIDDLE
5. GAIN - TREBLE
ese are for doing the Boost / Cut of Bass, Middle and Treble respectively. e set-
ting range is -9 to +9. It gets neutral at 0.
4. FREQUENCY - MIDDLE
is is for setting the Central Frequency to vary at Gain - Middle (#3).
e setting range is 480Hz - 2.9Hz.
EXTRA VOICE
6. GAIN - BASS
7. GAIN - MIDDLE
8. GAIN - TREBLE
ese are for doing the Boost / Cut of Bass, Middle and Treble respectively. e set-
ting range is -9 to +9. It gets neutral at 0.
9. FREQUENCY - MIDDLE
is is for setting the Central Frequency to vary at Gain - Middle (#7).
e setting range is 480Hz - 2.9Hz.
Frequency
Gain
TC
100Hz
0dB
+3dB
-15dB
-9dB
-3dB
1kHz 10kHz
0
-1
-5
-9
+9
Frequency
Gain
1kHz
0dB
+9dB
-9dB
Bass
Gain
Treble
Gain
Middle
Gain
Middle Freq.
THE EFFECTIVE USE OF THE MIDDLE FREQUENCY
The frequency response of the horn rotor in the
Leslie speaker is not at. It has a peak from 1kHz
to 3kHz that it is another component of the classic
HAMMOND sound.
When you use this organ on line out without a Le-
slie speaker, you can get the similar e ect by set-
ting the FREQUENCY - MIDDLE to about 2kHz, and
the GAIN - MIDDLE to “+”.
PRESET PARAMETERS
Equalizer is a Preset Parameter, designed to ac-
tively use as one of the tone-making parameters.
However, it is not practical to use Equalizer as a
tonal complementary tool to match the location.
In such a case, if you switch OFF the P. LOAD RV/EQ
in the PRESET function mode, the Equalizer value
does not change when the preset is recalled. (P. 60)
1 2 3 4 5
6 7 8 9
