Cools modules using a front-to-back airflow with alarm-monitored, low-noise fans
Control and Monitoring Using a 6800+ETH Module
Regulates and reports major frame operation and performance data to the control
system
Provides access to Ethernet for control and monitoring using CCS Navigator or a web
browser
Provides additional control via SNMP with the 6800+ETHSNMP option
Supports thumbnail transmission at a rate of three frames per second, for all modules
that support this feature within the frame, in CCS Navigator only
Power Supply
Houses two power supplies for full redundancy and load-sharing
Displays power and fault indicators on front panel
Includes captivated power cord(s) for AC power supplies to prevent accidental
unplugging (note: cords are not provided for the DC power supply configurations)
Provides choice of 6822+AC for AC power or 6800+48V for DC power; frame can
house two of either power supply or one of each
Includes a temperature-sensing submodule that provides alarm generation when the
frame is monitored by CCS Navigator
Component Descriptions
Components of the FR6822+ frame are described in the following sections:
Front Panel on page 2
Rear Panel on page 3
Fan Assembly on page 4
Power Supply on page 5
6800+ETH Resource Module on page 5
Front Panel
Figure 1-1 shows the front view of a FR6822+ frame; and identifies the location of status
LEDs, cooling fans, and front panel release screws. Figure 1-2 shows the inside of the
frame with the front panel removed.
