Chapter 2
Installation
10
Copyright © 2008-2011, Harris Corporation
Available Frame Configurations
There are several FR6822+ frame products and packages available. The FR6822+ family
includes the following:
Choosing 6800+ETH Upgrade Options
The basic 6800+ETH module is enabled for CCS and HTTP control. The following upgrade is
available:
To purchase additional license keys, contact your Sales representative. To activate a license
key, see Activating a 6800+ETH License in CCS Software on page 43 or Activating a
6800+ETH License Using an HTTP Browser on page 59.
Table 2-1 FR6822+ Frames and Accessories
Product Code Description
FR6822+QXFE 2RU frame with thumbnails, fan module, Ethernet module, and one
6822+AC power supply
FR6822+QXFE+48 2RU frame with thumbnails, fan module, Ethernet module, and one
48-volt power supply
FR6822+QXFE+S 2RU frame with thumbnails, fan module, Ethernet module with SNMP
license, and one 6822+AC power supply
FR6822+QXFE+S48 2RU frame with thumbnails, fan module, Ethernet module with SNMP
license, and one 48-volt power supply
FR6822+F 2RU frame with fan module and one 6822+AC power supply
FR6822+F+48 2RU frame with fan module, resource module, and one 48-volt power
supply
FR6822+RM Rear support extension rail, 6800+ series frames
6800+ETH Ethernet resource card for FR6822+QXFE, CCS
6800+ETHSNMP Ethernet resource module with SNMP
6800+48V 48-volt power supply
6822+AC Redundant, single 6822+AC power supply
Table 2-2 Available Soft-Key Upgrades
Ordered Product Content Description
6800+OPT+SNMP Optional soft-key upgrade to allow the host
frame and its modules to be controlled and
monitored using SNMP-based control
applications
