FR6822+F Frame and Module
Operation
Note: All the frame and module functionality described in this chapter also applies to
FR6822+QXFE frames. For information on remote control and monitoring of FR6822+QXFE
frames, see Chapter 4.
Monitoring the Frame Using Frame Status LEDs
Status LEDs indicate the health of your frame. Figure 3-1 shows the location of the Status
LEDs on the FR6822+ frame. Table 3-1 describes the three LEDs located on the front panel
of the FR6822+ frame.
Figure 3-1 Location of Status LEDs on the FR6822+ Frame
Status LEDs
Cooling Failure/Alarm/Power
