31
Copyright © 2008-2011, Harris Corporation
4
FR6822+QXFE Configuration,
Monitoring, and Control
Overview While a FR6822+ and its installed modules can be controlled at the card edge as described
in Chapter 3, FR6822+F Frame and Module Operation, there are many more control and
monitoring options with the addition of a 6800+ETH resource module. These are described
in the following sections:
Using CCS Software with FR6822+QXFE on page 31
Using an HTTP Browser with FR6822+QXFE on page 44
Control and Monitoring FR6822+QXFE Using SNMP on page 60
Basic 6800+ETH Module Operation on page 69
If you will only be using one monitoring system for your 6800+ devices (for example HTTP),
you can turn off notification methods for other communication protocols to reduce network
traffic. See Using CCS Software with FR6822+QXFE on page 31 for more information.
Note: Except where noted, the term 6800+ETH is used in this manual to refer to 6800+ETH
and 6800+ETHSNMP resource modules.
Using CCS Software with FR6822+QXFE
CCS configuration and control of FR6822+QXFE frames begins with the discovery process.
When you enter the IP address of the 6800+ETH module and run a discovery, all modules in
theFR6822+QXFE host frame are also discovered.
Note: 6800+ETH requires CCS software version 3.2.1 or higher for full functionality.
Once a 6800+ETH module is discovered in CCS Navigator, you can update its firmware and
change its IP address. You can adjust remote control parameters for 6800+ETH and the
modules in the host frame. If other modules in the 6800+ETH host frame are Q-SEE
compliant, you can view monitoring thumbnails for those modules.
See the following topics for more information:
Preparing for Configuration on page 32
Discovering Frames and Modules Using a CCS Application on page 32
Monitoring 6800+ Modules in CCS Navigator on page 33
Using Q-SEE Compliant Modules in FR6822+QXFE Frames on page 33
