FR6822+ Frames
Installation and Operation Manual
69
Copyright © 2008-2011, Harris Corporation
Walking 6800+ Modules of a Type
To walk all modules of a type in a frame, browse to Private > Enterprises > Leitch >
fam6800plus in the MIB tree, and then right click on the module type you wish to and
choose Walk.
Navigating Parameters in a MIB
Using MIBs, you can view a parameter’s range, walk a device or a frame, or receive alarm
traps for a device. How you access these standard features will depend on the MIB
browsing software you use. See the documentation that accompanies your third-party
control software for more details.
Parameters that have a limited list of options have two listings under the Entry branch of the
tree. Parameters that have a range (as in a slider) of options have four listings under the
Entry branch of the tree.
For information on the parameters for each individual device, see that device’s
documentation on our website. In addition, some products have HTML forms that display
their parameters. These HTML forms are also available on our website.
Basic 6800+ETH Module Operation
A 6800+ETH module has no card-edge controls, and is designed to work with control and
monitoring software. See the following topics:
Setting 6800+ETH Remote Control Parameters on page 69
Telnet Commands on page 70
For a general description of the 6800+ETH module and its card edge LEDs, see 6800+ETH
Resource Module on page 5.
Setting 6800+ETH Remote Control Parameters
6800+ETH has no card-edge controls. Table 4-7 lists all of the remote control parameters
and options for the 6800+ETH. You can access these parameters using CCS Navigator, or
an internet browser. If your 6800+ETH module includes the SNMP option, you can also
access these parameters using a third-party SNMP-based control application. See Control
and Monitoring FR6822+QXFE Using SNMP on page 60 for more information.
All parameters clip unless otherwise indicated.
Table 4-6 Sub-Branches Under a Parameter in a MIB
Sub-Branch Contains
Slot ID A unique slot identifier for this
entry
Value The current setting of this
parameter
High Range (slider ranges only) The top value of this parameter
Low Range (slider ranges only) The bottom value of this parameter
