Chapter 4
FR6822+QXFE Configuration, Monitoring, and Control
60
Copyright © 2008-2011, Harris Corporation
Figure 4-28 Discovery Options Dialog Box
2 Select the IP address for your 6800+ETH module, and then click Modify.
The Modify Host dialog box appears.
Figure 4-29 Modify Host Dialog Box
3 Select HTTP, and then click OK to close the Modify Host dialog box.
4 Click OK again to close the Discovery Options dialog box.
5 Click Start to run a discovery.
6 When your discovery is complete, click Save to transfer the results of the discovery to the
Navigation pane.
In Navigator’s Control mode, you can now double click on the 6800+ETH to launch a web
browser, where you can monitor the frame and modules.
Control and Monitoring FR6822+QXFE Using SNMP
SNMP is an industry-standard protocol that allows third-party control software to remotely
monitor and control devices. You can monitor a host frame through its 6800+ETH module
using any standard MIB browsing software.
