Chapter 6
Specifications
80
Copyright © 2008-2011, Harris Corporation
Power Supply Specifications
Unless otherwise specified, the FR6822+ frame comes with a single AC power supply. You
may have a second redundant power supply, or one or two DC power supplies, or one of
each. Power supplies are described in the following sections:
6822+AC Power Supply on page 80
6800+48V DC Power Supply on page 81
6822+AC
Table 6-3 6822+AC Power Supply
Item Specification
Physical Specifications
Size 1.45×11.25×3.35 in. (3.68×28.58×8.51 cm)
Weight 1.9 lb (0.85 kg)
Load step response Recovery to 1% of nominal within 4 msec
Minimum load No load
Ripple and noise <3% of nominal voltage
Over-voltage protection 120% ±10% of nominal output voltage
(13.6 V output only)
Temperature range 32°F (0°C) to 113°F (45°C)
Input Specifications
Input voltage 100 to 250 V AC (±10%)
Frequency 47 to 63 Hz
Input current
2 A rms maximum at 90 V AC, 120 W
output power
0.75 A rms maximum at 274 V AC, 120 W
output power
Inrush current
(maximum peak)
25 A
Efficiency >70% at 117 V AC, 120 W output (typical)
Power factor
>0.90 at 130 W output power
100 to 250 V AC input voltage
