Chapter 3
FR6822+F Frame and Module Operation
30
Copyright © 2008-2011, Harris Corporation
Wrapping is only available from the card edge. Parameters that normally wrap when
adjusted via the card edge will clip when adjusted using a control software application.
Adjustable Parameters
Two types of adjustable parameters can be changed using the card-edge controls:
Numerical parameters, which require you to select a value within a numerical range (for
example, between 0 and 524)
Selectable parameters, which require you to select a specific option (for example, 525
or 625)
Both numerical and selectable parameter changes are immediate.
Use the available 6800+ software controls (CCS Navigator, SNMP-based control application,
or web browser) to view and monitor parameter selections.
Note: See the table titled “Card-Edge Parameter Options” in the individual product manual
that accompanies your module to view the various numerical and selectable parameters for
the module.
Read-Only Parameters
Many of the read-only parameters have related LEDs on the front of the module’s card
edge. See the section “Monitoring LEDs” in the individual product manual that
accompanies your module for information on the location of these LEDs.
Operating
Notes
When setting the control parameters, observe the following:
If you make changes to certain parameters, other related parameters may also be
affected. See the section “Cross-Functional Parameter Changes” in the individual
product manual that accompanies your module for more information.
When you change a parameter, the effect is immediate. However, the module requires
up to 30 seconds to save the latest change. After 30 seconds, the new settings are
saved and will be restored if the module loses power and must be restarted.
Alarms Alarms are usually logged and monitored within available software control applications. You
can only identify alarms and differentiate between major and minor alarms within a
software control application, such as CCS Navigator, an HTTP web browser, or a third-party
SNMP-based control application (if your 6800+ETH module has the optional license key).
See Chapter 4, FR6822+QXFE Configuration, Monitoring, and Control for more
information.
