Helmer iB111 (Version A) - Refrigerator Setpoint; Temperature Alarm Setpoints

360077-1/O 111
Horizon Series™ - Laboratory, Pharmacy, and International Blood Bank Models
24.2 Refrigerator Setpoint
NOTE Default setpoint is 4.0 °C.
Change the setpoint if:
► Your organization requires a chamber temperature other than 4.0 °C.
► The normal chamber temperature is too high or low (after completing preventive maintenance and
applicable troubleshooting tasks).
Conrm:
► Refrigerator has been placed per location requirements in the operation manual.
► Preventive maintenance has been completed per operation manual.
► Troubleshooting items associated with chamber temperature have been reviewed (if necessary).
Change setpoint.
1 Determine the change in value to reach desired setpoint. Adjustment should be the difference
between current setpoint and new setpoint.
EXAMPLE ► Current setpoint is 4.0 °C
► Target setpoint is 5.0 °C
► Setpoint adjustment value is +1.0 °C
2 On the monitoring system, press and release SEL to change to Control mode. CONTROL lamp will
illuminate.
3 Press and hold SET to display the reference temperature.
4 Hold SET and press Up Arrow or Down Arrow as necessary to set the adjustment value determined
in step 2.
5 Release all buttons; the setpoint is changed.
6 Press and release SEL to return to Monitor mode. MONITOR lamp will illuminate.
24.3 Temperature Alarm Setpoints
View setpoints:
1 Hold Up Arrow and Down Arrowforthreeseconds.MONITORlampwillashtoindicateentryinto
program mode.
2 Press SEL until desired setting appears.
3 Observe the setting.
4 To view another setting, press SEL again (optional).
5 Hold Up Arrow and Down Arrowforthreeseconds.MONITORlampstopsashingtoindicateexit
from program mode.
Flashing Lamp Selected Setting
HIGH TEMP and MONITOR High temp alarm setpoint
LOW TEMP and MONITOR Low temp alarm setpoint
MONITOR only Monitor offset
CONTROL only Control sensor offset
CONTROL only Control hysteresis
