360077-1/O 11

General Information

3.2.1 i.Series Monitoring System and Independent Temperature Controller

NOTE This section applies to iB, iHB, iLR, and iPR models.

i.Series refrigerators are equipped with the i.Center monitoring system and independent temperature

controller.

i.Center monitor. Independent temperature controller.

3.2.2 Horizon Series Blood Bank Monitoring System and Independent Temperature Controller

Horizon Series blood bank refrigerators are equipped with the Horizon monitoring system and

independent temperature controller.

NOTE This section applies to HB models.

Horizon monitor. Independent temperature controller.
