360077-1/O 96

Horizon Series™ - Blood Bank Models

20.2 Top

A B C

Top features.

Label Description Part Number

Schematic

Label

A Monitoring system backup batteries 715031 AE

B Compressor unit Contact Helmer Technical Service A

C Condensing unit fan motor Contact Helmer Technical Service U
