Helmer iB111 (Version A) - Lighting; Unit Cooler

360077-1/O 130
Horizon Series™ - Laboratory, Pharmacy, and International Blood Bank Models
27.4.1 Lighting
A B
Light features.
Label Description Part Number
Schematic
Label
A Light assembly (models with stainless
steel interior)
115 V: 400508-1
230 V: 400508-2
M
B Light assembly (models with powder-
coated interior)
115 V: 400507-2
230 V: 400507-1
M
Not
shown
Light bulb 120409 -
27.4.2 Unit Cooler
A B
Left: Unit cooler (single-door model shown). Center and right: Unit cooler parts.
Label Description Part Number
Schematic
Label
A Unit cooler fan motor 115 V
111 models: 120540
120 and 125 models: 120411
245 and 256 models (one fan): 120587
245 and 256 models (two fans): 120410
230 V
111 models: 120560
120 and 125 models: 120415
245 and 256 models (one fan): 120588
245 and 256 models (two fans): 120545
H
B Temperature control probe HPR, HLR, and HHB models: 400511-1 G
