COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 163
Abbreviation Connector
AUX Auxiliary transmission connector
TISS Transmission input speed sensor
TOSS Transmission output speed sensor
MLPS Manual lever position switch (side of transmissino)
SL Shift Lever body connector
SI Shift lever Indicator (bezel)
8.6.11.2 TRANS 1 Connector
A 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
B 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
Note: This is the view into the receptacle on controller, not the plug.
CONNECTOR ROW PIN TERMINATIO
N
WIRE COLOR FUNCTION NOTES
TRANS 1 A 10 AUX-02 Yellow Solenoid SL2
TRANS 1 A 11 MAIN-08 White / Blue Solenoid S1
TRANS 1 A 12 MAIN-15 Brown / Yellow Solenoid S2
TRANS 1 A 4 MAIN-02 Brown Temperature Sensor
1 Ground
TRANS 1 A 5 TRANS TISS-1 Purple Input Shaft Speed
High
TRANS 1 A 6 TRANS TOSS-1 Purple / Yellow Output Shaft Speed
High
TRANS 1 A 7 MAIN-13 Green / Red Solenoid SLT
TRANS 1 A 8 MAIN-12 Green / White Solenoid SLU
TRANS 1 A 9 MAIN-11 Yellow / Blue Solenoid SL1
