COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 164
CONNECTOR ROW PIN TERMINATIO
N
WIRE COLOR FUNCTION NOTES
TRANS 1 B 1 MAIN-03 Black Solenoid Ground for
SL1
Or TRANS 2 B8
TRANS 1 B 1 MAIN-04 Black Solenoid Ground for
SLU
Or TRANS 2 B8
TRANS 1 B 1 AUX-04 Black Solenoid Ground for
SL2
Or TRANS 2 B8
TRANS 1 B 1 MAIN-05 Black Solenoid Ground for
SLT
Or TRANS 2 B8
TRANS 1 B 10 MLPS-7 Blue / Yellow MLPS Drive
TRANS 1 B 12 FLYING LEAD Yelow/Blk Transfer Case
Calculation
TRANS 1 B 2 MLPS-2 Black / White Ground for MLPS
TRANS 1 B 4 MAIN-10 Brown Temperature Sensor
1
TRANS 1 B 5 TRANS TISS-2 Purple Input Shaft Speed
Low
TRANS 1 B 6 TRANS TOSS-2 Purple / Yellow Output Shaft Speed
Low
TRANS 1 B 7 MLPS-6 Blue / Orange MLPS Park
TRANS 1 B 8 MLPS-1 Blue / Red MLPS Reverse
TRANS 1 B 9 MLPS-9 Blue / Black MLPS Neutral
Note that ground wires MAIN-03, MAIN-04, AUX-04, and MAIN-05 can be connected to TRANS 2 B8 instead of TRANS 1
B1, depending on wiring loom build variation.
8.6.11.3 TRANS 2 Connector
A 8 7 6 5 4 3 2 1
B 8 7 6 5 4 3 2 1
Note: This is the view into the receptacle on controller, not the plug.
