COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 167
CONNECT
OR
RO
W
PIN PIN NAME FUNCTION WIRE
COLOR
TERMINATION NOTE
S
ENGINE B 5 OD ON/OFF LED TO LED ON
SWITCH
BLU/RED FLYING LEAD
ENGINE B 6 OD CANCEL
SWITCH
SWITCH INPUT TO
ECM
BLU/YEL FLYING LEAD
ENGINE B 7 SWITCH SHIFT
UP
SHIFT UP WHT/RED FLYING LEAD
ENGINE B 8 SWITCH SHIFT
COM
GND OR COMMON WHT/RED FLYING LEAD
ENGINE B 9 SWITCH DOWN SHIFT DOWN WHT/BLK FLYING LEAD
ENGINE B 10 ENGINE TEMP
RETURN
ENGINE B 11 CAN1 - CAN BUS LOW
SIGNAL
ENGINE B 12 GND
In addition, the following other connections are assigned.
CONNECTOR ROW PIN TERMINATION WIRE COLOR FUNCTION
ENGINE B 5 SI-1 White / Blue S Mode Indicator
ENGINE B 6 SL-3 Brown / White S Mode
ENGINE B 7 SL-1 Brown / Yellow Shift Up
ENGINE B 8 SL-5 Black Ground
ENGINE B 8 SL-7 Black Ground
ENGINE B 9 SL-2 Brown / Red Shift Down
To Next Page
