HGM COMPUSHIFT II User Manual

COMPUSHIFT II Manual – COMPUSHIFT II Manual
Specifications & Pinouts– 168
OPTIONS Connector
A 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
B 1
2
1
1
1
0
9 8 7 6 5 4 3 2 1
Note: This is the view into the receptacle on controller, not the plug.
CONNEC
TOR
RO
W
PI
N
NAME FUNCTION WIRE
COLOR
TERMINATI
ON
NOTES
OPTIONS A 1 12 V 12 VOLT OUT
OPTIONS A 2 5 V 5 VOLT
DISPLAY
YELLOW DISPLAY
PLUG
OPTIONS A 3 CAN2+ CAN BUS 2
HIGH SIGNAL
OPTIONS A 4 RS232 TX DISPLAY RED DISPLAY
PLUG
OPTIONS A 5 LIN DATA COMMUNICATI
ON
OPTIONS A 6 NO
CONNECTION
OPTIONS A 7 NO
CONNECTION
OPTIONS A 8 NO
CONNECTION
OPTIONS A 9 SOLENOID 12 REVERSE
LAMP RELAY
Must drive relay,
not lamps directly.
