80
────────────────────────────────────────────────────
8.4 Command Reference
────────────────────────────────────────────────────
Synta
x
*
CLS
Functio
n
This instruction clears all the event registers associated with the bits of the
status byte register (SESR, and the corresponding bits of STB).
Not
e
This has no effect upon the output queue, the various enable registers, and
bit 4 (the MAV bit) of the status byte register.
Synta
x
*
ESE data
dat
a
0 to 255 (numerical data in NR1 format)
Functio
n
This instruction sets the standard event register (SESER) to a bit pattern
which is used to mask the standard event status register (SESR).
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
PON URQ CME EXE DDE QYE RQC OPC
Not
e
When the power is turned on, and when a reset taken place upon key input
(system reset), the data is reinitialized to zero.
Exampl
e
Transmission
*ESE 36
CME and QYE of SESER are set to 1.
Synta
x
*
ESE?
Functio
n
The contents of SESER as set by the
*
ESE command are returned as an
NR1 integral value (data) in the range 0 to 255.
Respons
e
Whether headers are on or off
data
Exampl
e
Transmission
Response
ESE?
36
*
CLS
*
ESE
*
ESE?
