Hioki 3237 - Page 91

79
_____________________________________________________________________________________________
7.4 Command Reference
______________________________________________________________________________________________
Syntax
[:SENSe:]CLAMp:MODel data
data
NRf numerical data
9010,9132,9018,3283,9270,9271,9272,9277,9278,9279,3284,3285
Function
Selects the clamp sensor to be used in clamp current measurement.
Example
Transmission CLAM:MOD 9132
Syntax
[:SENSe:]CLAMp:MODel?
data
NR1 numerical data
Function
Inquires about the model of the clamp sensor currently set.
Response
syntax
Headers: ON :SENSE:CLAMP:MODEL data
Headers: OFF data
Syntax
[:SENSe:]VOLTage[:DC]:REFerence data
[:SENSe:]VOLTage:AC:REFerence data
[:SENSe:]CURRent:DC:REFerence data
[:SENSe:]CURRent:AC:REFerence data
[:SENSe:]RESistance:REFerence data
[:SENSe:]LPResistance:REFerence data
[:SENSe:]FRESistance:REFerence data
[:SENSe:]LPFResistance:REFerence data
[:SENSe:]CLAMp:DC:REFerence data
[:SENSe:]CLAMp:AC:REFerence data
[:SENSe:]FREQuency:REFerence data
data
NRf numerical data
Function
Sets the Zero-Adjsted value. When the Zero-Adjust function is active, the unit returns a
measurement value obtained by subtracting the Zero-Adjusted value.
Note
If the NRf numerical value data is set to a value larger than the maximum value (minimum value, if
negative) that can be measured with each function, an execution error will be issued.
Example
Transmission VOLT:REF 13.63
Sets 13.63 V as the Zero-Adjusted value of the DC voltage measurement
function. When the Zero-Adjust function is active, the unit outputs a value that
results from subtracting 13.63 V as the measurement value.
Setup for clamp sensor
Inquiry concerning clamp sensor
Setup for Zero-Adjusted value
