8.4 Communication Methods
Status Byte Register (STB)
During serial polling, the contents of the 8-bit Status Byte Register are
sent from the instrument to the controller.
When any Status Byte Register bit enabled by the Service Request
Enable Register has switched from 0 to 1, the MSS bit becomes 1.
Consequently, the SRQ bit is set to 1, and a service request is
dispatched.
The SRQ bit is always synchronous with service requests, and is read
and simultaneously cleared during serial polling. Although the MSS bit
is only read by an
*STB? query, it is not cleared until a clear event is
initiated by the
*CLS command.
Service Request Enable Register (SRER)
This register masks the Status Byte Register. Setting a bit of this
register to 1 enables the corresponding bit of the Status Byte Register
to be used.
Bit 7 unused
Bit 6
SRQ Set to 1 when a service request is dispatched.
MSS This is the logical sum of the other bits of the
Status Byte Register
.
Bit 5
ESB
Standard Event Status (logical sum) bit
This is logical sum of the Standard Event Status Register.
Bit 4
MAV
Message available
Indicates that a message is present in the output queue.
Bit 3 unused
Bit 2 unused
Bit 1
ESB1
Event Status (logical sum) bit 1
This is the logical sum of Event Status Register 1.
Bit 0
ESB0
Event Status (logical sum) bit 0
This is the logical sum of Event Status Register 0.
