37
4.1 Selecting Measurement Functions
Settings Select the Resistance, Low-Power Resistance or Temperature
measurement function.
Basic Function
Settings Chapter 4
4.1 Selecting Measurement Functions
Switching the Measurement Function
1
Confirm the SHIFT lamp is not lit.
2
Switches the displayed measurement function.
Each key-press switches the measurement function.
Resistance Measurement display
(
Ω unit indicator lit, LP indicator
off)
Low-Power Resistance
Measurement display
(
Ω unit indicator lit, LP indicator
lit)
Temperature Measurement
display
( °C unit indicator lit)
(Main Display)
If the OF indicator
appears with temperature
measurement.
❖ If the temperature sensor is set to Pt: 3.2 Temperature Measurement
(Temperature Correction & Conversion) (Page 31)
Check whether the temperature probe is connected properly.
If it is not, temperature cannot be measured.
To Next Page
