4.4 Sampling Rate Setting
42
Settings
The sampling rate can be selected from FAST, MEDIUM, SLOW1 and
SLOW2. Slower sampling rates generally provide greater
measurement precision.
4.4 Sampling Rate Setting
Selecting the Sampling Rate
The sampling rate changes as follows with each key-press.
FAST MED SLOW1 SLOW2
• When AUTO self-calibration is enabled and FAST or MED
sampling is selected, self-calibration is performed for about 55 ms
once every 30 minutes.
❖ 5.8 Self-Calibration (Page 66)
• With FAST sampling selected, measurements can be easily
affected by the external environment, so countermeasures such as
shielding of the sample and test leads are recommended. Shields
should be connected to the SOURCE-L side.
To Next Page
