Hioki 3541 User Manual

57
5.3 Averaging Function
Function
Description
The Averaging Function averages measurement values for output.
This function can minimize instability of displayed values.
The number of samples to average can be set from 2 to 100.
5.3 Averaging Function
Setting the Number of Samples to Average
1
(SHIFT Lamp lit)
The Averaging Function setting display appears.
2
Select ON.
3
The number of samples to average setting blinks.
4
Select the number of samples to average.
5
The Average Measurement display appears. (AVG lit)
(Main Display)
(Sub Display)
(Sub Display)
Or
ten-keys
Disabling the Averaging Function
1
(SHIFT Lamp lit)
The Averaging Function setting display appears.
2
Select OFF.
3
The Averaging Function is disabled. (AVG off)
(Main Display)
(Sub Display)
• When the internal trigger is used for continuous measurement
(free-run), the display shows the moving average (default setting).
Otherwise, the display shows the integrating average.
❖ Trigger setting: 5.11 Trigger Function (Page 68)
❖ Averaging method (Page 161)
• When FAST sampling rate is used and measurement current is
small (approx. 100 µA or less), power line noise may cause
instability in measurement values. In such cases, even increasing
the number of samples to average may not provide significant
improvement. To suppress the noise, thoroughly shield the test
object and leads, or change to MEDIUM, SLOW1 or SLOW2
sampling rate.
