7.5 Printing
Printing Measured Values and Decision Results _____________________
From the Measurement display, press the PRINT key or ground the
PRINT
pin in the EXT I/O connector to print the measured value and
decision result.
Interval printing ________________________________________________
This function allows you to automatically print out measurement
results at preset intervals. The print interval time must be set from the
Interface Selection display.
❖ 7.3 Interface Selection (Page 92)
The setting range is 1 to 3600 seconds.
When the print interval time is set to "0", interval printing is disabled,
and only normal printing is carried out.
Operation when interval printing is selected
• Start printing by pressing the PRINT key or sending the
PRINT
signal via EXT I/O.
• Elapsed time (hours/minutes/seconds) and measurement values
are printed automatically at intervals corresponding to the preset
interval time.
• Stop printing by pressing the PRINT key or sending the
PRINT
signal via EXT I/O again.
Printing Statistical Calculation Results_____________________________
From the Statistical Calculation display, press the PRINT key to print
statistical calculation results. If no valid data exists, only the data count
is printed. When only one valid data sample exists, standard deviation
of sample and process capability indices cannot be printed.
7.5 Printing
• When using the external trigger, if you want to print after a
triggered measurement finishes, connect the EOC signal of the
External I/O to the PRINT
signal.
• To print all measurements continuously, connect the EOC signal to
the PRINT
signal and enable the internal trigger.
When the actual time has exceeded 99 hours, the elapsed time
information will be fixed to 99 hours.
